Stainless steel tube fitting manufacturer improves productivity with new all-electric tube benders

Wellington, New Zealand, March 23, 2016 --- Two new all-electric tube bending machines are helping Ultibend Industries to boost the manufacturing productivity of stainless steel tube fittings for food and beverage processing systems. Customized to suit Ultibend's proprietary manufacturing process, the machines from Unison automate the bending of tube fitting shapes such as elbows and U-bends, in sizes from 1/2 to 4 inches diameter. Initial manufacturing operations have demonstrated that the new machinery boosts manufacturing speed compared with the previous hydraulic bending process.



Ultibend started in 1992 as a subcontract tube bender, supplying architectural pipework. The company also found a market for tubular parts for the strong local food processing industry, and evolved from sub-contract work into offering a broad range of stainless steel tube fitting parts for applications including food, winery, brewery, dairy and sanitary processing.



As part of the company's development, Ultibend designed and manufactured its own tube bending machines. There are now four of these machines and they have served Ultibend well, but they are hydraulically powered - and critically for the future development of the company - only offer a very basic level of machine and operator control. As the company has expanded, it became interested in upgrading the bending process with more flexible all-electric machines - using software-controlled servomotor controlled bending. Developing its own solution to this upgrade would involve familiarity with servomotor based motion control as well as much more sophisticated machine control and interfacing software - and it was viewed as too big a step for the Ultibend engineering team. So, it decided to look to the commercial market for an upgrade.



Ultibend settled on Unison as the supplier, largely because of the fact that it had started life as a machine controls and software supplier and that a large proportion of its output was customized.



"We didn't want a standard machine, so discovering Unison was great. Their willingness to customize - and the fact that they are genuine machine control experts - gave us confidence that we would get the far-reaching solution that we were searching for," says Ultibend's co-founder and director, Linc Turley. "The investment means that our business now has the manufacturing platform to support substantial growth, including our current expansion into the USA and other new export markets."



One of Ultibend's unique advantages is the very high functional quality of its tube fittings. Bends are highly uniform, with the kind of ovality tolerances that would normally only be found in an aerospace workshop. This quality level is achieved by Ultibend's proprietary manufacturing process, which means that bent parts are exceptionally uniform as they come off the machine. Ultibend also developed its own clamping system, which allows short elbow and U-shape parts to be gripped and bent at the expense of trimming only a miniscule amount of scrap material. Both of these techniques have been incorporated in Unison's new customized machine design.



"Unison's customizetion capability means that we've been able to emulate unique features Ultibend uses in its process, and then exploit the all-electric machine architecture to enhance productivity," says Jim Saynor, Unison's Senior Commercial Manager. "The result is that the two new machines have increased output- while also providing much richer programming, networking and operator control facilities to open up further opportunities for progress."



The main reason the Unison machines speed the bending is the inherently greater control of motion that's possible inside Unison's software-controlled, all-electric machine architecture. The software gearbox is able to control and coordinate several axes simultaneously for instance, avoiding the delays of a more mechanical machine such as the latency in response of a slave axis.



www.unisonltd.com



ENDS

About Unison.

Unison started in business by developing control systems for metalworking machinery – supplying a number of prominent UK machine manufacturers in the 1970s and 1980s. In 1991 the company moved into machinery design, focusing on machines for tube bending. At that time, tube bending machines were powered hydraulically. In the early 1990s Unison invented a range of machines employing electrical servo-motors for controlling bending motion. These were the world’s first 'all-electric' machines for tube bending. The performance of Unison's new machine design – with its fast and repeatable software-controlled set-up, right-first-time action, low power consumption, and quiet and clean operation – was an instant success. The company has progressively led the tube bending machinery industry by increasing the tubing diameters that can be formed using all-electric motion and is now one of the world’s leading manufacturers of tube bending machines and associated software. In 2014, Unison took another quantum leap in power by developing a servomotor-powered machine architecture that is capable of bending thick-walled piping with diameters of 225 mm and more. The company opened its own direct support center in North America in 2015. www.unisonltd.com



For more information about Unison, please contact Dale Coates at:

Unison Tube LLC, 1465 Sand Hill Road, Suite 2016, Candler NC 28715, USA. t: 828 633 3190; toll-free: 844 734 1533; fax: 828 633 3188; www.unisonltd.com



About Ultibend Industries.

Ultibend Industries is a family owned stainless steel tube fittings manufacturer situated in Elsdon, Porirua City (Wellington), New Zealand. Ultibend is an international supplier of quality stainless steel tube elbows and fittings which are made primarily at the New Zealand factory. Ultibend was established in 1992 by two brothers and has expanded to employ approximately 20. Ultibend Industries' vision is to be market leaders in the supply of stainless steel tube elbows and fittings. Ultibend established a subsidiary company, ES3 Ltd, in 2012, which provides customers with 2D and 3D laser profile cutting. www.ultibend.com


Ultibend Industries, 15 Raiha Street, Elsdon, Porirua City, Wellington 5022, New Zealand. t: +64 4 237 4060; info@ultibend.com Editorial contact: Linc Turley.
